Oracle遞歸查詢簡單示例

目錄

• 1 數據準備
• 2 start with connect by prior遞歸查詢
• 2.1 查詢所有子節點
• 2.2 查詢所有父節點
• 2.3 查詢指定節點的，根節點
• 2.4 查詢巴中市下行政組織遞歸路徑
• 3 with遞歸查詢
• 3.1 with遞歸子類
• 3.2 遞歸父類
• 補充：實例
• 總結

1 數據準備

create table area_test(  id number(10) not null,  parent_id  number(10),  name       varchar2(255) not null);alter table area_test add (constraint district_pk primary key (id));insert into area_test (ID, PARENT_ID, NAME) values (1, null, "中國");insert into area_test (ID, PARENT_ID, NAME) values (11, 1, "河南省"); insert into area_test (ID, PARENT_ID, NAME) values (12, 1, "北京市");insert into area_test (ID, PARENT_ID, NAME) values (111, 11, "鄭州市");insert into area_test (ID, PARENT_ID, NAME) values (112, 11, "平頂山市");insert into area_test (ID, PARENT_ID, NAME) values (113, 11, "洛陽市");insert into area_test (ID, PARENT_ID, NAME) values (114, 11, "新鄉市");insert into area_test (ID, PARENT_ID, NAME) values (115, 11, "南陽市");insert into area_test (ID, PARENT_ID, NAME) values (121, 12, "朝陽區");insert into area_test (ID, PARENT_ID, NAME) values (122, 12, "昌平區");insert into area_test (ID, PARENT_ID, NAME) values (1111, 111, "二七區");insert into area_test (ID, PARENT_ID, NAME) values (1112, 111, "中原區");insert into area_test (ID, PARENT_ID, NAME) values (1113, 111, "新鄭市");insert into area_test (ID, PARENT_ID, NAME) values (1114, 111, "經開區");insert into area_test (ID, PARENT_ID, NAME) values (1115, 111, "金水區");insert into area_test (ID, PARENT_ID, NAME) values (1121, 112, "湛河區");insert into area_test (ID, PARENT_ID, NAME) values (1122, 112, "舞鋼市");insert into area_test (ID, PARENT_ID, NAME) values (1123, 112, "寶豐市");insert into area_test (ID, PARENT_ID, NAME) values (11221, 1122, "尚店鎮");

2 start with connect by prior遞歸查詢

2.1 查詢所有子節點

select *from area_teststart with name ="鄭州市"connect by prior id=parent_id

2.2 查詢所有父節點

select t.*,levelfrom area_test tstart with name ="鄭州市"connect by prior t.parent_id=t.idorder by level asc;

start with 子句：遍歷起始條件，如果要查父結點，這里可以用子結點的列，反之亦然。
connect by 子句：連接條件。prior 跟父節點列parentid放在一起，就是往父結點方向遍歷；prior 跟子結點列subid放在一起，則往葉子結點方向遍歷。parent_id、id兩列誰放在“=”前都無所謂，關鍵是prior跟誰在一起。
order by 子句：排序。

2.3 查詢指定節點的，根節點

select d.*,	   connect_by_root(d.id) rootid,	   connect_by_root(d.name) rootnamefrom area_test dwhere name="二七區"start with d.parent_id IS NULLconnect by prior d.id=d.parent_id

2.4 查詢巴中市下行政組織遞歸路徑

select id, parent_id, name, sys_connect_by_path(name, "->") namepath, levelfrom area_teststart with name = "平頂山市"connect by prior id = parent_id

3 with遞歸查詢

3.1 with遞歸子類

with tmp(id, parent_id, name) as (	select id, parent_id, name    from area_test    where name = "平頂山市"    union all    select d.id, d.parent_id, d.name    from tmp, area_test d    where tmp.id = d.parent_id   )select * from tmp;

3.2 遞歸父類

with tmp(id, parent_id, name) as  (   select id, parent_id, name   from area_test   where name = "二七區"   union all   select d.id, d.parent_id, d.name   from tmp, area_test d   where tmp.parent_id = d.id   )select * from tmp;

補充：實例

我們稱表中的數據存在父子關系，通過列與列來關聯的，這樣的數據結構為樹結構。

現在有一個menu表，字段有id，pid，title三個。

查詢菜單id為10的所有子菜單。

SELECT * FROM tb_menu m START WITH m.id=10 CONNECT BY m.pid=PRIOR m.id;

將PRIOR關鍵字放在m.id前面，意思就是查詢pid是當前記錄id的記錄，如此順延找到所有子節點。

查詢菜單id為40的所有父菜單。

SELECT * FROM tb_menu m START WITH m.id=40 CONNECT BY PRIOR m.pid= m.id ORDER BY ID;

總結
